Запчасти для экскаватора KOMATSU PC40
В наличииЗапчасти для экскаватора KOMATSU PC40
от 1 000 грн
+380 (66) 045-13-45
Сергей Описание
Характеристики
Информация для заказа
Менеджер Сергей -
- +38(066) 045 13 45
- sales@d-bt.com.ua
Менеджер Анатолий -
- +38(050) 156 17 52
- a.dobosh@d-bt.com.ua
Спецтехника Komatsu используется в строительных и горнонобывающих работах по всему миру, в процессе эксплуатации возникает необходимость в замене изношенных запчастей, у нас вы можете купить оригинальные и аналоги запчастей для комацу в Украине. Так же поставляем б/у запчасти для техники Комацу. Безналичный и наличный расчет.
В наличии более 10 000 позиций для Komatsu, а именно:
- Фильтры и смазочные материалы
- Ходовая часть (опорные катки, гусеницы, пальцы, звездочки итд.)
- Болты, гайки и элементы крепления
- Коронки, зубья, адаптеры, пальцы, фиксаторы
- Ножи, режущие кромки
- Подушки амортизационные
- Пальцы и Втулки
- Запчасти двигателя (прокладки, сальники, кольца итд)
- Гидравлика
- Трансмиссия
- Стартеры и генераторы
Если вы не нашли каталожный номер на нашем сайте, пожалуйста уточняйте наличе у наших менеджеров.
Возможна срочная доставка необходимой позиции в течении 5 рабочих дней.
Оказываем сервисные услуги на объекте заказчика.
Доступные к заказу позиции для экскаваторов комацу модельного ряда KOMATSU PC40:
| 20T-70-01150 | ARM ASS'Y |
| 20T-970-0150 | ARM ASS'Y,(FOR ATTACHMENT) |
| 20T-70-01370 | ARM ASS'Y,(FOR MULTI) |
| 20T-70-81250 | BUSHING |
| 20T-62-82270 | HOSE |
| 20T-70-81780 | SPACER 1.0MM |
| 20T-63-X2425 | CYLINDER GROUP,BUCKET |
| 20T-63-X2480 | CYLINDER GROUP,BUCKET (FOR MULTI) |
| 20T-943-0080 | ARM ASS'Y |
| 20T-943-8210 | HOSE |
| 07086-20411 | HOSE |
| 20T-970-8410 | TUBE |
| 07238-10424 | CONNECTOR |
| 10T-49-13180 | NIPPLE |
| 20T-970-8420 | STOP VALVE |
| 07042-00415 | PLUG |
| 112-50-11141 | STOPPER |
| 20S-970-7652 | BRACKET |
| 01010-81055 | BOLT |
| 20T-70-01130 | LINK ASS'Y |
| 20T-70-81411 | LINK |
| 01010-82045 | BOLT |
| 20U-70-24530 | LINK,L.H. |
| 20U-70-24540 | LINK,R.H. |
| 20T-70-01320 | LINK ASS'Y |
| 20U-70-24720 | LINK |
| 20T-970-9690 | BUSHING |
| 07145-00065 | SEAL,DUST |
| 20T-70-84210 | PIN |
| 20U-70-24850 | GUARD |
| 20U-70-24890 | PIN |
| 20U-70-24910 | PIPE |
| 01011-81210 | BOLT |
| 20T-71-00240 | BLADE ASS'Y |
| 20T-71-81120 | EDGE,CUTTING (WELDED) |
| 20T-71-81140 | BUSHING |
| 20T-70-81720 | SPACER 1.0MM |
| 20T-63-02441 | CYLINDER ASS'Y,BLADE |
| 20T-70-81770 | SHIM 1.0MM |
| 20T-910-0041 | BLADE ASS'Y |
| 20T-910-0040 | BLADE ASS'Y |
| 20T-910-8130 | BRACKET |
| 20T-910-8150 | BRACKET |
| 20T-910-8560 | EDGE |
| 20T-910-8170 | PIN |
| 20T-910-8180 | PIN |
| 20T-63-02451 | CYLINDER ASS'Y,BLADE |
| 20T-910-0050 | FRAME ASS'Y |
| 20T-910-8240 | PIN |
| 20T-63-02461 | CYLINDER ASS'Y,TILT |
| 20T-63-02460 | CYLINDER ASS'Y,TILT |
| 20T-910-8250 | COVER |
| 20T-910-8260 | COVER |
| 20T-910-8290 | COVER |
| 20T-63-X2470 | CYLINDER ASS'Y,ANGLE |
| 20T-98-81120 | PLATE MARK,KOMATSU |
| 20T-46-82270 | SEAT,SLIP PROTECTION |
| 20T-98-87110 | PLATE MARK,MACHINE MODEL |
| 20T-98-82340 | PLATE MARK,LUBRICATION STANDARD |
| 20M-98-73130 | PLATE CAUTION,KEEP OUT OF TURNING AREA |
| 20T-98-72381 | PLATE CAUTION,FUEL TANK |
| 09653-03001 | PLATE SAFETY,HYDRAULIC OIL CAP |
| 09668-03001 | PLATE SAFETY,RADIATOR CAP |
| 09963-03001 | TAG |
| 09654-03001 | PLATE SAFETY,LOCK LEVER |
| 09801-03000 | PLATE SAFETY,HAZARDOUS VOLTAGE HAZARD |
| 09802-03000 | PLATE SAFETY,BEFORE OPERATION |
| 09651-03001 | PLATE SAFETY,OPERATION AND MAINTENANCE |
| 09657-03001 | PLATE SAFETY,TRACK ADJUSTING |
| 20T-98-82140 | PLATE CAUTION,HYDRAULIC TANK |
| 20T-98-82150 | PLATE CAUTION |
| 09960-01001 | PLATE MARK |
| 09960-01012 | PLATE MARK |
| 20T-98-72511 | PLATE OPERATING,WORK EQUIPMENT PATTERN |
| 09822-03000 | PLATE SAFETY,WORK EQUIPMENT PATTERN |
| 01370-10308 | SCREW,(FOR TOPS CANOPY) |
| 20T-98-82450 | PLATE CAUTION,AIR CLEANER |
| 20T-98-72521 | PLATE OPERATING,WORK EQUIPMENT PATTERN |
| 09803-03000 | PLATE SAFETY,AUTO LOCK |
| 20U-46-22230 | SHEET |
| 20T-54-82240 | PLATE |
| 20T-98-82510 | PLATE MARK,LUBRICATION STANDARD |
| 20M-98-74130 | PLATE CAUTION,KEEP OUT OF TURNING AREA |
| 09653-01001 | PLATE SAFETY,HYDRAULIC OIL CAP |
| 09668-01001 | PLATE SAFETY,RADIATOR CAP |
| 09963-01001 | TAG |
| 09963-01000 | TAG,DO NOT OPERATE |
| 09654-01001 | PLATE SAFETY,LOCK LEVER |
| 09801-01000 | PLATE SAFETY,HAZARDOUS VOLTAGE HAZARD |
| 09802-01000 | PLATE SAFETY,BEFORE OPERATION |
| 09651-01001 | PLATE SAFETY,OPERATION AND MAINTENANCE |
| 09657-01001 | PLATE SAFETY,TRACK ADJUSTING |
| 20T-98-82520 | PLATE CAUTION,HYDRAULIC TANK |
| 20T-98-82530 | PLATE CAUTION |
| 20T-98-82540 | PLATE CAUTION,AIR CLEANER |
| 20T-98-73511 | PLATE OPERATING,WORK EQUIPMENT PATTERN |
| 09822-01000 | PLATE SAFETY,WORK EQUIPMENT PATTERN |
| 20T-98-73521 | PLATE OPERATING,WORK EQUIPMENT PATTERN |
| 09803-01000 | PLATE SAFETY,AUTO LOCK |
| 20T-98-05100 | SPARE PARTS KIT |
| YM119808-12520 | ELEMENT |
| YM129612-42290 | V-BELT |
| YM22190-220002 | SEAL,RING |
| 120-98-05120 | CLOTHES KIT |
| 20R-98X-1101 | TOOL KIT |
| 708-1T-01112 | PUMP,SUB |
| 708-1T-01111 | PUMP SUB ASS'Y |
| 708-1T-04211 | CASE SUB ASS'Y |
| 01252-61250 | BOLT |
| 04020-00616 | PIN |
| 07000-11009 | O-RING |
| 708-1T-04320 | CAP |
| 708-1T-04221 | CAP SUB ASS'Y |
| 708-1T-12122 | SHAFT |
| 708-1T-11250 | BEARING |
| 708-1T-12310 | SPACER |
| 708-1T-11260 | BEARING |
| 708-1T-05010 | SPACER KIT |
| 708-1T-11880 | SEAL,OIL |
| 708-1T-11890 | SPACER |
| 04065-05020 | RING,SNAP |
| 708-1T-13110 | BLOCK,CYLINDER |
| 708-1T-13221 | PLATE,VALVE |
| 708-1T-13130 | WASHER |
| 708-1T-13151 | SPRING |
| 708-1T-13350 | RETAINER,GUIDE |
| 708-2L-23360 | PIN |
| 708-1T-13340 | RETAINER,SHOE |
| 708-1T-13310 | PISTON SUB ASS'Y |
| 708-1T-14210 | BOLT,ADJUST |
| 07002-13034 | O-RING |
| 708-1T-14311 | PLUG |
| 01583-02414 | NUT |
| 708-1T-15141 | PLUG |
| 01582-01210 | NUT |
| 07002-11223 | O-RING |
| 708-1T-15121 | SEAT |
| 708-1T-14410 | SLIDER |
| 708-1T-15590 | SEAT |
| 708-1T-03513 | ..VALVE SUB ASS'Y,PC |
| 708-1T-15114 | ...PISTON |
| 708-1T-14140 | ...PISTON |
| 708-1T-15153 | ...PLUG |
| 708-1T-15132 | ...PLUG |
| 700-90-61281 | ...SEAL |
| 708-1T-14322 | ...SPRING |
| 708-1T-03722 | VALVE ASS'Y,LS |
| 708-1T-15521 | PISTON |
| 708-1T-15530 | SLEEVE |
| 708-1T-15542 | SPOOL |
| 708-1T-15560 | PLUG |
| 708-1T-15570 | SPRING |
| 708-1T-15580 | BALL |
| 708-1T-15750 | SEAT |
| 708-1T-15760 | SPRING |
| 708-1T-15770 | SEAT |
| 708-1T-15790 | PLUG |
| 07000-11008 | O-RING |
| 07001-01008 | RING |
| 705-41-01920 | GEAR PUMP ASS'Y |
| 705-41-81010 | BRACKET ASS'Y |
| 705-41-81020 | BRACKET |
| 705-41-83130 | COVER ASS'Y |
| 705-41-83140 | COVER |
| 705-40-80970 | PLUG |
| 705-40-83720 | PLATE,SIDE |
| 705-40-22610 | GEAR,DRIVE |
| 705-41-80830 | BOLT |
| 708-1T-19210 | COUPLING |
| 700-30-63140 | RING,SNAP |
| 708-1T-19230 | RING |
| 07000-11006 | O-RING |
| 708-1T-19140 | TEE |
| 708-1T-19313 | ORIFICE |
| 07235-50210 | ELBOW |
| 708-1T-19440 | TUBE |
| 708-1T-15952 | PLUG |
| 07000-11004 | O-RING |
| 07001-01004 | RING |
| 04530-11018 | BOLT |
| 708-1T-19610 | TUBE |
| 20B-27-11210 | BLEEDER |
| 072-35-10210 | ELBOW |
| 01010-80845 | BOLT |
| 20T-63-02402 | CYLINDER ASS'Y,BOOM |
| 20T-63-57441 | CYLINDER |
| 20T-870-1290 | BUSHING |
| 707-29-90281 | HEAD,CYLINDER |
| 20T-63-57421 | ROD,PISTON |
| 707-76-50740 | BUSHING |
| 707-71-60480 | PLUNGER |
| 20T-63-57471 | TUBE |
| 707-98-25560 | SERVICE KIT,BOOM CYLINDER |
| 20T-63-X2703 | CYLINDER GROUP,BOOM |
| 20T-63-02703 | CYLINDER ASS'Y,BOOM |
| 20T-63-57643 | CYLINDER |
| 707-76-55450 | BUSHING |
| 707-29-11140 | HEAD,CYLINDER |
| 07000-12105 | O-RING (KIT) |
| 07146-02106 | RING,BACK-UP (KIT) |
| 707-35-91140 | RING,BACK-UP (KIT) |
| 20T-63-57622 | ROD,PISTON |
| 707-76-55470 | BUSHING |
| 707-71-60550 | PLUNGER |
| 707-36-11100 | PISTON |
| 707-44-11180 | RING,PISTON (KIT) |
| 07156-01112 | RING,WEAR (KIT) |
| 20T-63-57673 | TUBE |
| 707-98-34610 | SERVICE KIT,BOOM CYLINDER |
| 20T-63-02433 | CYLINDER ASS'Y,BOOM SWING |
| 20T-63-02432 | CYLINDER ASS'Y,BOOM SWING |
| 20T-63-87442 | CYLINDER |
| 20T-63-87441 | CYLINDER |
| 20T-63-88420 | ROD,PISTON |
| 20T-63-88481 | TUBE |
| 20T-63-88480 | TUBE |
| 20T-63-02414 | CYLINDER ASS'Y,ARM |
| 20T-63-67442 | CYLINDER |
| 707-76-45470 | BUSHING |
| 20T-63-67422 | ROD,PISTON |
| 20S-70-81140 | BUSHING |
| 20T-63-68480 | TUBE |
| 707-98-25250 | SERVICE KIT,ARM CYLINDER |
| 20T-63-02425 | CYLINDER ASS'Y,BUCKET |
| 20T-63-77444 | CYLINDER |
| 707-29-70350 | HEAD,CYLINDER |
| 07000-12065 | O-RING (KIT) |
| 07146-02066 | RING,BACK-UP (KIT) |
| 20T-63-77421 | ROD,PISTON |
| 707-36-70360 | PISTON |
| 707-44-70180 | RING,PISTON (KIT) |
| 07156-00710 | RING,WEAR (KIT) |
| 20T-63-78373 | TUBE |
| 20T-63-78381 | TUBE |
| 707-98-15690 | SERVICE KIT,BUCKET CYLINDER |
| 20T-63-02480 | CYLINDER ASS'Y,BUCKET |
| 20T-63-77540 | CYLINDER |
| 20T-63-77520 | ROD,PISTON |
| 20T-63-78480 | TUBE |
| 20T-63-97440 | CYLINDER |
| 707-76-55430 | BUSHING |
| 20T-63-97420 | ROD,PISTON |
| 703-06-92110 | SHAFT,SWIVEL |
| 703-08-98510 | PLUG |
| 703-09-98710 | PLUG |
| 703-06-91110 | ROTOR |
| 703-06-98110 | SEAL,OIL |
| 07000-15060 | O-RING |
| 703-06-95122 | SEAL,SLIPPER |
| 703-06-95121 | SEAL,SLIPPER |
| 703-06-94110 | RING |
| 04064-05520 | RING,SNAP |
| 703-06-93110 | COVER |
| 703-06-98310 | O-RING |
| 01252-31035 | BOLT |
| 703-06-98230 | PIN |
| 708-7R-11611 | PLATE,SWASH |
| 708-7R-11710 | WASHER |
| 708-7R-11720 | FILTER |
| 708-7R-04011 | HOUSING SUB ASS'Y |
| 708-7R-11220 | PLUG |
| 708-7R-11210 | VALVE |
| 07000-02125 | O-RING |
| 01252-61230 | BOLT |
| 708-7R-12111 | SHAFT |
| 708-7R-12140 | BEARING |
| 708-7R-12150 | BEARING |
| 708-7R-13111 | BLOCK,CYLINDER |
| 708-7R-13210 | PLATE,VALVE |
| 708-7R-13540 | PIN |
| 708-7R-13530 | WASHER |
| 708-7R-13560 | SPRING |
| 708-7R-13520 | SPRING |
| 04065-03012 | RING |
| 708-7R-13510 | GUIDE,RETAINER |
| 708-7R-13340 | RETAINER,SHOE |
| 708-7R-13310 | PISTON SUB ASS'Y |
| 708-7R-13410 | PLATE,THRUST |
| 708-7R-13581 | SPACER |
| 708-7R-13570 | SPACER |
| 708-7R-15130 | PLATE |
| 708-7R-15121 | DISC |
| 708-7R-15140 | PISTON,BRAKE |
| 07000-12110 | O-RING |
| 708-7R-15170 | RING,BACK-UP |
| 708-7R-15150 | SPRING |
| 708-7R-15160 | RING |
| 708-7R-15712 | PISTON |
| 708-7R-15722 | SPRING |
| 708-7R-03010 | VALVE SUB ASS'Y |
| 708-7R-15670 | SPRING |
| 706-73-72680 | PLUG |
| 708-7T-02180 | RELIEF VALVE ASS'Y |
| 708-7T-02150 | RELIEF VALVE ASS'Y |
| FUGHB50-1-8322 | BODY SUB ASS'Y |
| FUFZD-8322-02 | COVER |
| FUGHC50-1-8322 | CARRIER SUB ASS'Y |
| FUGHC50-2-8391 | CARRIER SUB ASS'Y |
| FUFZD-8391-07 | GEAR |
| FUFZD-8391-08 | GEAR |
| FUFZD-8322-21 | NEEDLE |
| FUFRP-1078-21 | THRUST WASHER |
| FUFZD-8391-09 | GEAR |
| Основные | |
|---|---|
| Производитель | Komatsu |
| Страна производитель | Япония |
| Гарантийный срок | 12 мес |
| Состояние | Новое |
| Тип техники | Спецтехника |
- Цена: от 1 000 грн
